Road Roller
XS 143J
XCMG XS143J Single drum vibratory roller is ideal machine for road construction & haul road maintenance application. Heavy loaded drive axle and nonskid differential mechanism can furthest transfer the output power as well as the tractive force of engines.
Download Brochure| Engine model | Shanghai Diesel Engine SC4H140.1G2 |
|---|---|
| Rated power | 103 KW/1800rpm |
| Engine Type | 4 Cylinder, Turbo Charged & Direct Injection |
| Static Linear load | 315 N/cm |
|---|---|
| Vibration frequency | 28/33 Hz |
| Nominal Amplitude (High/Low) | 1.9 / 0.95 mm |
| Exciting force | 274/190 kN |
| Compaction width | 2130 mm |
| Transmission | 3 Forward & 2 Reverse |
|---|---|
| 1st Forward / Reverse | 2.85 / 2.88 Km/h |
| 2nd Forward-II | 5.08 / 5.02 Km/h |
| 3rd Forward-III | 11.17 Km/h |
| Max. gradeability | 30% |
| Track radius inner | 6800 mm |
| Braking Distance | <4.6 |
| Tyre Size | 20.5 - 25 |
|---|---|
| Fuel Tank Capacity | 310 Litters |
| Dimension(LxWxH) | 6150*2340*3200 mm |
